Characteristics of GOHSENOL™

Gas Impermeability

GOHSENOL™ films formed either independently or on other materials such as paper show very high impermeability to many kinds of gases such as oxygen, nitrogen, hydrogen, carbon dioxide, and helium ; however, moisture and ammonia can permeate the films.

Oxgen Permeability (Dry condition)
Resin OTR (cc20μm / m2・day)
GOHSENOL™ (N type)                0.0050
Ethylene vinyl alcohol copolymer 1)           0.07
Nylon 6     76
Polypropylene 3900

1) : Ethylene 29mol%
